Panel Sizing Wood and Standard Plastic Saws Model PS9Z
Raptor Systems
Your Machinery Experts and High Engineering Solutions Company!
Raptor Systems ++1-780-438-6188
Wood Saws Single-Axis
Veneer Saws
Multi-Axis Saws
Technical Data:
Cutting length: 3200/3800/4200/5800 mm
Material pusher capacity: 3200/3800/4200/5800 mm
Saw blade projection: 103 mm
Main saw motor: 9-13 kW/50 Hz or 10-15 kW/60 Hz
Scoring saw motor: 1,1 kW
Main saw blade diameter: 355 mm
Scoring saw blade diameter: 127 mm
Saw carriage forward speed: 5-100 m/min
Saw carriage return speed: 130 m/min
Material pusher forward speed: 25 m/min
Material pusher return speed: 80 m/min
Cutting length: 3200/3800/4200/5800 mm
Material pusher capacity: 3200/3800/4200/5800 mm
Saw blade projection: 103 mm
Main saw motor: 9-13 kW/50 Hz or 10-15 kW/60 Hz
Scoring saw motor: 1,1 kW
Main saw blade diameter: 355 mm
Scoring saw blade diameter: 127 mm
Saw carriage forward speed: 5-100 m/min
Saw carriage return speed: 130 m/min
Material pusher forward speed: 25 m/min
Material pusher return speed: 80 m/min
The panel saw for fast and precise cutting is the Mayer PS9Z. Whether a single sheet, or a full book is being machined, this saw is not only powerful, but also fast and versatile.
Important details for your machining advantage:
Trip stops for cutting panels with overhanging veneer or plastic laminate coverings.
Electronic groove equipment.
Power Pack II increased feed speed of the saw carriage. Also optimized opening height of the pressure beam, with cutting height and cutting length adjustment. This gives extreamly short cutting cycles.
Control for doing cut outs (also known as window cutting) in the panels.
A postforming unit ensures an all around chip free cut on panels with post or softformed edges.
Automatic cutting height setting facility, guarantees the correct saw blade projection every time.
The machine guarantees:
A dimensionally accurate finish cut over years of use with a wear free hardened and ground cylindrical guide way for both the saw carriage and the material pushing system.
Precise parallel cuts are achieved by the use of a material pusher guide on the two sides, and driven by a precision rack and pinion system.
Maximum dimensional stability with measurements taken by a backlash free measuring system, which operates independently of the drive unit. The measurement is taken by a magnetic tape which ensures superior and constant accuracy.
Short cutting cycles due to the optimized saw movement and pressure beam opening.
The material pusher is guided by a hardened and ground cylindrical guide way and prism rollers.
Important details for your machining advantage:
Trip stops for cutting panels with overhanging veneer or plastic laminate coverings.
Electronic groove equipment.
Power Pack II increased feed speed of the saw carriage. Also optimized opening height of the pressure beam, with cutting height and cutting length adjustment. This gives extreamly short cutting cycles.
Control for doing cut outs (also known as window cutting) in the panels.
A postforming unit ensures an all around chip free cut on panels with post or softformed edges.
Automatic cutting height setting facility, guarantees the correct saw blade projection every time.
The machine guarantees:
A dimensionally accurate finish cut over years of use with a wear free hardened and ground cylindrical guide way for both the saw carriage and the material pushing system.
Precise parallel cuts are achieved by the use of a material pusher guide on the two sides, and driven by a precision rack and pinion system.
Maximum dimensional stability with measurements taken by a backlash free measuring system, which operates independently of the drive unit. The measurement is taken by a magnetic tape which ensures superior and constant accuracy.
Short cutting cycles due to the optimized saw movement and pressure beam opening.
The material pusher is guided by a hardened and ground cylindrical guide way and prism rollers.
Note how each clamp has 2 clamping points. This guarantees positive clamping, also for narrow strips
